    14k/min Temperature Changing Rate Environmental Test Chambers For Reliability Testing

    Ask Lasest Price
    Brand Name : BOTO
    Model Number : BT-TH-100
    Certification : CE ISO9001
    Payment Terms : L/C, T/T
    Supply Ability : 100 Set/Sets per Month
    Delivery Time : 5-25 days
    • Product Details
    • Company Profile

    14k/min Temperature Changing Rate Environmental Test Chambers For Reliability Testing

    14k/min Temperature changing Rare Rapid Rate Temperature Cycle Test Chamber

    Technical Parameters

    Name
    14k/min Temperature changing Rare Rapid Rate Temperature Cycle Test Chamber
    Model
    BT-TH-100
    BT-TH-225
    Internal Dimension (mm)
    400*500*500
    500*600*750
    Overall Dimension (mm)
    860*1050*1620
    960*1150*1860
    Interior Volume
    100L
    225L
    Low type
    A: -40℃ B:-70℃ C -86℃
    Temperature Range
    -20℃ ~+150 ℃
    Temperature Fluctuation
    ± 0.5 ℃
    Temperature Deviation
    ± 2.0 ℃
    Cooling Rate
    1 ℃ / min
    Heating Rate
    3 ℃ / min
    Refrigerant
    R404A, R23
    Controller
    Programmable color LCD touch screen controller
    Temperature Sensor
    PTR Platinum Resistance PT100Ω/MV A-class, accuracy 0.001℃
    Exterior Material
    Steel Plate with protective coating
    Interior Material
    SUS304 stainless steel
    Standard Configuration
    1 Cable hole (Φ 50,) with plug; 2 shelves
    Power Supply
    220V 50Hz / 380V 50Hz
    Maximum Noise
    65 dBA
    Environmental Conditional
    5℃~+35 ℃ ≤85% RH

    Detail Design

    Test Area

    1.SUS304 stainless steel 2.Internal Dimension:50L and 80L 3.Rust-proof to high and low temperature and moisture corrosion; 4.Adjustable sample shelves, facilitate the various sizes of test samples.

    Cable Hole

    1.Inner hole diameter is 50mm. 2.Convenient for the cable to pass through,and provide power for the test piece 3.Reliably Sealing 4.Customizable test hole size

    Controller

    1.PID programmable color touch screen controller 2.Can be network connection computer 3.Can edit 100 programs 100 segments 4.Multiple languages are available

    Advantage
    1.Multiple model:T-100,T-225,T-500,T-800,T-1000 2.Testing small and large test pieces,Can be powered 2.Low types: -20℃/-40℃/-60℃/-70℃/-86℃ 3.Free calibration 4. 72 hours commissioning before delivery to ensure product performance
